Hi,
I have followed the link: https://learn.microsoft.com/en-us/azure/cloud-adoption-framework/ready/azure-best-practices/private-link-and-dns-integration-at-scale.
I want to convert private endpoint name to ip address, when VM and private endpoint are in different VNets, as shown in the figure. The figure has a private DNS resolver. But the samme problem without the implementation of the private DNS resolver.
Thanks a lot before hand.
Best regards
Liu
Hello Zhou Liu
Also,
Could you share the necessary details in a private message so we can continue troubleshooting?
I hope this has been helpful!
If the above is unclear or you are unsure about something, please add a comment below.
Hello Ganesh,
Thank you for your suggestion. But I am quite sure that applying DNS resolvers inbound ip on VM will not help. My drawing shows that all VNets have the private DNS resolver as DNS server. The figure shows also the output of VM1's nslookup, where you can see that VM1 is using the inbound ip as DNS server.
By the way, VM2 behaves similar as VM1, i.e. nslookup works for webapp02 (in the same VNet), not webapp01.
Best regards
Liu
Hello Zhou Liu
Thanks for the reply!
I have Initiated a private message with you. Please provide the following details so I can continue troubleshooting the issue.
Hi,
I have updated my figure, so that both output of "nslookup" from vm1 and vm2 is shown. It seems that private endpoint in HUB works fine with DNS resolver, but not in spokes.
Best regards
Liu
